If you live or camp off the grid or plan to then you’ll need to figure out and plan how you’re going to cook off the grid. There are several ways and fuel choices and I’ll talk about those below. If you have any other suggestions or ideas then please leave those in the comments section below.

Propane

The use of propane is easy and quick.  A small propane stove could be purchased and then stored until the need for use.  Propane is clean and produces good heat for cooking and canning.  The downside of a stove/oven would be the amount used.  Either multiple bottles or a large tank would be needed to keep operating it during a SHTF scenario.

A propane fish cooker would be a second option.  With the proper regulator, gas usage would be minimal.  The cooker would be large enough to can food or just cook a meal.  As a plus, in the event that you would have to bug-out, the cooker would be able to be loaded in a vehicle and carried with you to another location.

The use of a propane camp stove is a good third option, either using 1 pound bottles or a hose connector.  An adapter is made to refill the 1 pound bottles which would help out in the long-term. The use of a gas grill would allow you to cook also.

With the storage of propane the use of a grill would allow portability with a large cooking area.  Grills can be used with either bottles or hooked to a large tank for long-term use. All four of these options allow the use of a camp oven.

Storage of propane is simple and the propane does not go bad in storage.

White Gas

Camping stoves that use white gas are available new, in stores, or for sale used.  They cook very well.  A downside of these stove are fuel storage and parts/repair kits. White gas usually comes in metal cans which can rust and cause leakage.  Fuel viability over long-term would be iffy.  Parts kits are available, but, when they are gone, they’re gone.

These are very portable and yes, you can use a camp oven with these too.

Charcoal

Charcoal, either lump or briquettes, are a good option for cooking food.  Charcoal can be used with a grill or can be used with a dutch oven.  Dutch ovens will allow you to bake or stew meals as an alternative to using other methods of cooking.  Charcoal can be made by burning wood in a low oxygen environment.

Charcoal storage is easy.  The use of metal barrels or trash cans will keep it dry and ready to use.  Moisture is the enemy to worry about. Although not very portable, concerning space used, if you are staying put this is a good alternate source of cooking.

A camp oven can be used with most grills too. WORD OF CAUTION:  the use of charcoal indoors is VERY DANGEROUS as carbon monoxide poisoning is a deadly and real threat if it is used indoors.

Cooking with wood

Cooking with wood allows many and variable options also.  Getting a wood burning cook stove would be the ultimate in wood cooking.  These stoves have many options that could allow baking, cooking, and even heating water for clean up or bathing.  As a bonus, the cook stove can be used to heat during the winter.

Cleaning and amount of wood used are minor drawbacks.  Cooking in the summer would be a chore, but if the stove is put in a room that would allow a cooling breeze to enter and carry out the heat, it would be bearable.  If a room was added to an existing structure then it could be open in the summer and closed off during the winter so as to allow the heat to remain in the home.

Rocket stoves and wood gas stove allow cooking with the use of minimal wood.  These are available for purchase on the internet or can be made with pipe or even tin cans.  Heavier stoves that can be made would last a lifetime. The use of a camp oven could be used with the making of some type of bracket system to hold it off of the fire.

A rocket mass heater can be made to include an oven and a stove top to cook on.  Mass-heaters are a good way to heat but would have a few drawbacks for cooking.  Portability would be a big issue for some.  Using it to cook would heat a room and continue to radiate heat for even days.

No smoke or very little smoke would be a very large added plus though.  If a way to move air and remove excess heat were taken into consideration, then this would be a good option for bugging in.

A fireplace can be used to cook on if care is taken to reduce the risk of fire.  A fireplace does not use fuel very efficiently though.  When using a fireplace to cook with, a plume of smoke would also give away your position.

But, the chimney would also send the smell of cooking higher into the air and would dissipate the odors faster and better.  It would be very hard to use a camp oven with a fireplace but it could be done.

In a rural setting or suburban setting, wood can be gotten with a little effort or even just picking up sticks and branches around the yard or neighborhood.  Cutting of firewood after the fact would be a large chore that would burn a lot of energy.

But, with a good sharp axe or saw, the effort can be minimized.

Kerosene

Kerosene stoves and even burners can be had on the market.  Some of the stoves include ovens and even hot water tanks.  The kerosene burners would allow the use of a camp oven without the expense of a full-size stove.

Kerosene can be stored longer than gasoline or white gas but will still go bad over time.

Solar

Solar ovens can be bought online or made with wood and mirrors.  They can even be made with cardboard and aluminum foil.  These ovens can be used to cook with as long as the sun is shining and you have the time to wait.  Very good used to cook all day meals as a slow cooker.  Some of the ones purchased, allow baking bread and treats as it will get to very high temperatures.

Mud / Cob stoves

Cob stoves can be made using local materials usually.  With sand, clay, and some labor you can make an oven that can be a focal point at a backyard BBQ or used in a SHTF scenario.  These can be used to make bread or cook in an oven type environment.

Heat retention is very good and you can bake multiple batches of bread at a time.  If this is built outside, then some type of cover would be needed to keep the rain off of it.  This will prolong the life of your hard work.

The oven can be heated using rocket stove technology or even a fire built inside of it and using the coals for heat.  As it is being built, rocket stove inserts can be added at the side to have access to stovetop cooking.  The use of a wok for frying or cooking would be an added bonus.  The oven can be made of cob or as a steel box with racks and a door.

Wood Ovens

Ovens can be bought with wood stoves or kerosene stoves.  Wood ovens can be bought and used in bad times.  Ovens can be bought or made.  A camping oven can be bought or you can go all the way to large wood-fired ovens that could even cook a turkey.

Ovens can be made using cob, steel, even brick. You can make simple ovens using an ammo can.  But the easiest would probably be a large rural mailbox.  It is large enough to bake in by turning it on its side.

The door is ready-made.  If it burns out, more are readily available in a rural setting.  Large ammo cans are thicker metal and would last longer, but the latch would have to be modified to make it more user-friendly.  Dutch ovens are good for cooking and are used with coals or charcoal.

All in all, there are many ways to cook.  These may range in price from many thousand dollars down to free.  It can just depend on the time and effort you are willing to spend on your project.

by Dr. Arthur T. Bradley

According to the Nuclear Regulatory Commission, there are sixty-one active commercial nuclear plants spread across the United States. A question on the minds of many is what would happen to those plants if the nation experienced a widespread, long-lasting power outage?

Let me start by saying that there is a quite a bit of misinformation on the web about this subject, so my advice is to be careful about what you choose to believe.

Many of you may know that I have a background in science and engineering (Ph.D. in Electrical Engineering), so I believed that if I could talk with a knowledgeable person working in the nuclear power industry, I could get to the bottom of this question.

To find answers, I consulted Jim Hopson, the Manager of Public Relations at the Tennessee Valley Authority. As readers may point out, it was in Mr. Hopson’s interest to assure me that nuclear plants are safe, but to be fair, I found him to be forthright about the industry’s safeguards and vulnerabilities.

Probably the best place to start is with a basic discussion of how a nuclear power plant operates. There are two types of reactors in the U.S., boiling water reactors (BWRs) and pressurized water reactors (PWRs). For the purposes of our discussion, the differences in their operation aren’t terribly important. Nuclear reactors use an atomic process called fission to generate heat.

The heat is then used to create steam that turns large turbines to generate electricity. The steam is later condensed and returned in a closed-loop process within the reactor system.

The nuclear reaction itself is beyond the scope of this brief write up (and my expertise), but the gist is that an energetic neutron is absorbed by a uranium-235 nucleus, briefly turning it into a uranium-236 nucleus.

The uranium-236 then splits into lighter elements, releasing a large amount of energy. The physical system inside the reactor consists of tens of thousands of nuclear fuel rods placed into a water bath. The rods are essentially long metal tubes filled with ceramic nuclear pellets that are bundled together into larger assemblies. Trivia bit… a nuclear fuel pellet is about the size of a pencil eraser but equivalent in energy to one ton of coal.

The risks of nuclear power are many, but two stand above the rest. The first is that the fuel assemblies in the reactor might overheat. That would only occur if the fission process became uncontrolled or if the cooling system failed. Should overheating occur, the fuel rods’ zirconium cladding and nuclear materials could both melt, resulting in a nuclear sludge akin to molten lava. That slag would be so hot that it might melt through the bottom of the reinforced reactor.

Eventually, it would cool enough to harden, but not before it had spewed nuclear contaminants into the air. Melting zirconium also releases hydrogen, which could lead to an explosion that might actually expel the nuclear material into the surrounding area—think Fukushima.

The good news is that nuclear fission can be stopped in under one second through the insertion of control rods. Those control rods are automatically inserted near the fuel rods either by a hydraulic system or through the use of an electromagnetic deadman switch that activates when power is removed. That means that when the electrical grid goes down or an emergency shutdown is initiated, fission would automatically stop one second later.

That’s a good thing, but it doesn’t make the reactor inherently safe. Even without fission, the fuel rod assemblies remain incredibly hot, perhaps a thousand degrees C. If they were not actively cooled, pressure and temperatures would build in the reactor until something breaks—not good.

After three days of active cooling, however, the reactor would be thermally cool enough to open, should it be deemed necessary to remove the fuel rod assemblies.

The second major risk has to do with the cooling of the spent fuel rod assemblies. Nuclear fuel rod assemblies have a usable life on the order of 54-72 months (depending on reactor type). Every 18-24 months, the reactor is brought down and serviced. While it is down, the fuel rod assemblies are removed, and 1/3 of them are replaced with fresh assemblies.

Think of this like rotating cans of food in your emergency pantry. In the U.S., fuel rods are not refurbished like in other countries. Instead, they are carefully stored in giant pools of water laced with boric acid—imagine a swimming pool at your local YMCA that is 75-feet deep.

Those spent fuel rod assemblies are still incredibly radioactive, and they continue to generate heat. Water in the pool must, therefore, be circulated to keep them cool. How long must the fuel rods be cooled? According to Mr. Hopson, the answer is 5-7 years.

After that, the rods are cool enough to be removed and stored in reinforced concrete casks. Even then, the rods continue to be radioactive, but their heat output can be passively managed.

Nuclear plants obviously require electricity to operate their cooling pumps, not to mention their control systems. That power is normally tapped off of the electricity that the reactor generates. If the plant is offline, the power is provided by the electrical grid.

But what happens when the grid itself goes down? The short answer is that large on-site diesel generators automatically activate to provide electricity. And if those should fail, portable diesel generators, which are also on-site, can be connected. Recent standardization has also ensured that generators can be swapped between plants without the need to retrofit connectors.

There are also a couple of additional emergency systems that can be used specifically to cool the reactor. These include the turbine-driven-auxiliary-feedwater pump, which uses steam generated by the reactor to power a cooling turbine.

The pump requires an operator, but it runs completely without electricity. This system, however, is meant only for emergency cooling of the reactor during those critical first few days when the fuel rod assemblies are being brought down in temperature, not for long-term cooling.

And finally, in the worst case, most plants have a method of bringing in river or ocean water to flood the reactor. This typically damages the cooling system, but again, it helps to cool and cover the reactor core should all else fail. Unlike in other countries, permission from the federal government is not required to flood the reactor.

With backup systems to the backup systems, it would seem that there’s nothing to worry about, right? Under all but the direst of circumstances, I think that assessment is correct. However, one could imagine a scenario in which the grid was lost and the diesel generators ran out of fuel. Speaking of fuel, how much is actually stored onsite?

It depends on the plant, but at the Watts Bar Nuclear Plant, for example, there is enough fuel to run the emergency diesel generators for at least 42 days. I say at least because it would depend on exactly what was being powered.

Once the reactor was cooled down, a much smaller system, known as the Residual Heat Removal System, would be all that was required to keep the fuel assemblies cool, both in the reactor and the spent fuel rods pool.

The generators and onsite fuel supply could power that smaller cooling system for significantly longer than if they were powering the larger reactor cooling system. Even if we assumed a worst-case of forty-two days, it’s hard to imagine a scenario in which that would not be enough time to bring in additional fuel either by land, water, or air.

Nonetheless, let’s push the question a little further. What would happen in the unlikely event that the diesel fuel was exhausted?

Even with the reactor having been successfully cooled, the biggest risk would continue to be overheating of the fuel rod assemblies, both in the reactor and the spent fuel rods pool. Without circulation, the heat from the fuel rod assemblies could boil the surrounding water, resulting in steam.

In turn, the water levels would drop, ultimately exposing the fuel rods to air. Once exposed to air, their temperatures would rise but not to the levels that would melt the zirconium cladding. Thankfully, that means that meltdown would not occur. The steam might well carry radioactive contaminants into the air, but there would be no release of hydrogen and, thus, no subsequent explosions.

The situation would certainly be dangerous to surrounding communities, but it wouldn’t be the nuclear Armageddon that many people worry about.

The bottom line is that in the event of a long-duration blackout, several things would need to occur. First, fission would need to be halted by the insertion of control rods, a process that takes less than one second. Next, the reactor would need to be cooled for at least three days using the large diesel engines to provide electrical power. After that, the fuel rods would be cool enough that the reactor could be opened, and the plant’s Residual Heat Removal System could be used to provide cooling.

That smaller system would need to operate for 5-7 years to ensure that the fuel rod assemblies, both in the reactor and in the spent fuel rods pool, didn’t overheat. Only then could the fuel rod assemblies be moved to concrete casks for dry storage and final dispositioning. During those 5-7 years, electricity in one form or another would be required.

If it was not maintained, radioactive contamination could be released into the air, but the temperatures of the fuel rods would not be high enough to cause a complete meltdown or the dangerous release of hydrogen.

The point of this article wasn’t to convince anyone that nuclear power generation is safe. I would argue that history has already proven that it comes with some very serious risks. Rather, it was to discuss the impact of a long-duration blackout.

Specifically, it focused on the safeguards that are currently in place, and more importantly, discussed the magnitude of the catastrophe that might result if we allowed those safeguards to fail.
